รายละเอียดสินค้า:
|
| Function: | compression test,Paper Tube Compressive Strength Test,Burst tester,tensile test,Paper Testing Instrument | Name: | paper cup tube compressive strength tester,Paper testing instrument paper gsm tester/ bursting strength tester,paper testing instrument |
|---|---|---|---|
| Display: | LCD,Digital display | Feature: | easy to operate |
| Operation Method: | Automatic | Product Type: | Testing Instruments |
| Protection Device: | Induction type protection device | Control: | PLC control |
| Sensing Method: | Pressure Transmitter | Stop: | Stop test |
| Force Resolution: | 1/500000 of the maximum test force fs | Sample Size: | 100(L)×63(W)mm |
| Dropping Height: | 300mm-1500mm | Vibration Mode: | reciprocating |
| Test Cycles Setting: | 4 digits pre-set counter | ||
| เน้น: | Pulp Testing Sieve Content Analyzer,HD-P001 Sieve Content Analyzer,Somerville Sieve Content Analyzer |
||
| Attribute | Value |
|---|---|
| Function | Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument |
| Name | Paper cup tube compressive strength tester, Paper testing instrument paper GSM tester/bursting strength tester |
| Display | LCD, Digital display |
| Feature | Easy to operate |
| Operation Method | Automatic |
| Product Type | Testing Instruments |
| Protection Device | Induction type protection device |
| Control | PLC control |
| Sensing Method | Pressure Transmitter |
| Stop | Stop test |
| Force Resolution | 1/500000 of the maximum test force FS |
| Sample Size | 100(L)×63(W)mm |
| Dropping Height | 300mm-1500mm |
| Vibration Mode | Reciprocating |
| Test Cycles Setting | 4 digits pre-set counter |
| Sieve plate size | 307mm×268mm |
| Screen slit | Length 45 mm, width 0.15 mm |
| Specification of sieve plate sieve slit | 0.15mm |
| Rubber membrane and actuation: Amplitude | 3.2 ± 0.1mm eccentric actuation at 690-700 rpm |
| Water flow rate control | 8.6 L/min. Water pressure: 1.23 Kg/cm² |
| Dimensions | 720*410*1150mm |
| Other optional sieve plate sieve slot specifications | 0.15mm, 0.2mm, 0.3mm, 0.35mm, 0.4mm |
